321 904 U Profile Stainless Steel C Channel
Item | U Profile Stainless Steel Angle Bar | |||
Size | Specification: 20*20-200*200mm Thickness: 6m-12m (Size can be customized.) | |||
Surface | N0.1, N0.4, 2D, 2B, HL, BA, 6K, 8K, Mirror,etc | |||
Surface Treatment | Hot Dip Gavalnized / Black / Painted | |||
Material | Stainless Steel / Carbon Steel | |||
Grade | 201/202/304/316/Q235/Q345/SS400/Duplex stainless steel,etc | |||
Standards | AISI ASTM JIS SUS DIN GB | |||
Certifications | ISO 9001 | |||
Packing | Industry standard packaging or according to client’s requirement | |||
Payment | T/T,L/C,Western Union,Paypal,Apple Pay,Google Pay,D/A,D/P,MoneyGram | |||
Delivery time | Up to order quantity, usually delivery from factory within 7 days | |||
Common Chemical Composition
Grade | C | Si | Mn | P | S | Ni | Cr | Mo |
201 | ≤0.15 | ≤0.75 | 5.5-7.5 | ≤0.06 | ≤ 0.03 | 3.5-5.5 | 16.0-18.0 | – |
301 | ≤0.15 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 6.0-8.0 | 16.0-18.0 | – |
304 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 8.0-10.5 | 18.0-20.0 | – |
304L | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 9.0-13.0 | 18.0-20.0 | – |
316 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 |
316L | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 12.0-15.0 | 16 .0-1 8.0 | 2.0-3.0 |
321 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 9.013 | 17.0-1 9.0 | – |
410 | ≤0.15 | ≤1.0 | ≤1.0 | ≤0.035 | ≤ 0.03 | – | 11.5-13.5 | – |
430 | ≤0.12 | ≤0.75 | ≤1.0 | ≤0.040 | ≤ 0.03 | ≤0.60 | 16.0-18.0 | – |
Specifications | size | Kg / M |
5# | 50*37*4.5 | 5.438 |
6.3# | 63*40*4.8 | 6.634 |
8# | 80*43*5.0 | 8.045 |
10# | 100*48*5.3 | 10.007 |
12# | 120*53*5.5 | 12.059 |
14#A | 140*58*6.0 | 14.535 |
14#B | 140*60*8.0 | 16.733 |
16#A | 160*63*6.5 | 17.24 |
16#B | 160*65*8.5 | 19.752 |
18#A | 180*68*7.0 | 20.174 |
18#B | 180*70*9.0 | 23 |
20#A | 200*73*7.0 | 22.337 |
20#B | 200*75*9.0 | 25.777 |
22#A | 220*77*7.0 | 24.999 |
22#B | 220*79*9.0 | 28.453 |
25#A | 250*78*7.0 | 27.41 |
25#B | 250*80*9.0 | 31.335 |
25#C | 250*82*11.0 | 35.26 |
28#A | 280*82*7.5 | 31.427 |
28#B | 280*84*9.5 | 35.823 |
28#C | 280*86*11.5 | 40.219 |
30#A | 300*85*7.5 | 34.463 |
30#B | 300*87*9.5 | 39.173 |
30#C | 300*89*11.5 | 43.883 |
32#A | 320*88*8.0 | 38.083 |
32#B | 320*90*10.0 | 43.107 |
32#C | 320*92*12.0 | 48.131 |
36#A | 360*96*9.0 | 47.814 |
36#B | 360*98*11.0 | 53.466 |
36#C | 360*100*13.0 | 59.118 |
40#A | 400*100*10.5 | 58.928 |
40#B | 400*102*12.5 | 65.204 |
40#C | 400*104*14.5 | 71.488 |
