5005 5052 5754 H32 Tread Brite Diamond Plate 2.5mm Free Sample
Brief introduction
1100 Tread Brite Diamond Plates is one of the representatives of 1 series pure aluminum sheet, which is used for industry.It is not difficult for us to find the last two Arabic digits 00 in grade 1100.In fact, this represents more than 99.00% aluminum in1100 aluminum sheet on an international scale.The aluminum content of 99.00% makes the1100 aluminum sheetretain the advantages of the aluminum itself to the greatest extent.For example, it has excellent ductility of pure aluminum, high corrosion resistance, excellent conductivity and thermal conductivity.At the same time, with the addition of a small part of the alloy component Cu, the processability and surface processing of 1100 aluminum sheet and other alloy characteristics are enhanced, which can be better used for large storage tanks, food and chemical handling and storage equipment, sheet metal products, welding assemblies, reflectors, nameplates and so on.
Tread Brite Diamond Plate PARAMETERS
Chemical Components of 1100 Anti-Slip Aluminum Checkered Sheets
Elements | Si | Fe | Cu | Mn | Zn | Others | Al |
Content | 0.95 | 0.95 | 0.05-0.2 | 0.05 | 0.1 | 0.15 | Remain |
Anti-Slip Aluminum Checkered Sheets Specification
Typical alloy | 1100 Anti-Slip Aluminum Checkered Sheets |
Material temper | F, O, H12, H14, H16, H18, H19, H22, H24, H26, H28, H111, H112 |
Thickness (mm) | 0.1-500 |
Width (mm) | 20-2650 |
Length (mm) | Customize |
Typical product | Large storage tanks, Bus doors, Cooking utensils, Welding assemblies,Heat exchangers, etc |
Tread Brite Diamond Plate APPLICATION AND FEATURES
Excellent corrosion resistance
1100 aluminum sheet has good resistance to atmospheric (including industrial atmospheric and Marine vapor) corrosion and water corrosion.In addition, it can resist the corrosion of most acids and organics.
Good ductility and molding
1100 Anti-Slip Aluminum Checkered Sheets can produce various aluminum materials through pressure processing, which can adapt to the larger speed of most machine tools for turning, milling, boring, planing and other mechanical processing.
No low-temperature brittleness
1100 aluminum sheetbelow 0℃,as the temperature decreases, its strength and molding will not reduce, but increase.
DETAILED USAGE AND APPLIANCE
1100 aluminum sheet is industrial pure aluminum, which is usually used for parts requiring good forming and machining performance, high corrosion resistance and no high strength.
USES 1
1100 aluminum sheetcan be used forlarge storage tanks, food industrial installations, deep blanking, bottle caps, wide curtain walls, bus interior, bus doors/engine boards, decoration, heat exchangers, aluminum for transformers, heat sink, hardware, etc.
USES 2
1100 aluminum sheet/foil/coil material is widely used foraluminum plastic board, electronic foil, battery foil, etc.
