Asme B16.9 Mss Sp-43 Aisi 304/304l/316/316l Seamless Butt Weld Ss Pipe End Caps 2 Inch
Stainless Steel End Caps For Pipes Quick Details
Ss Pipe End Caps are pipe fittings that are used to seal off the ends of pipes. They are typically used to protect the ends of pipes from damage or to provide a clean, finished appearance. Stainless steel end caps are available in a variety of sizes and shapes to fit different types of pipes. They can be used with pipes made of stainless steel, as well as other materials such as carbon steel, brass, and copper.
There are several types of stainless steel end caps, including cap ends, beveled ends, and square ends. Cap ends are used to seal off the end of a pipe and are available in both weld-on and threaded versions. Beveled ends are used to connect pipes at an angle and are typically welded onto the end of a pipe. Square ends are used to seal off the end of a pipe and have a square cross-section.
Ss Pipe End Caps are widely used in a variety of industries, including oil and gas, chemical processing, water treatment, and construction. They are known for their corrosion resistance, strength, and durability.
- Technics:
- cold press
- Connection:
- Welding
- Shape:
- Equal
- Head Code:
- round
- Product name:
- Carbon Stainless Alloy Steel Welding Welded Pipe Dish End Cap
- MOQ:
- 1 Pcs
- Size:
- 1/2″ up to 110″
- Wall thickness:
- SCH 5s-SCH XXS
- Standard:
- ASTM DIN EN BS JIS GOST etc.
- Surface treatment:
- sand blasting, roll blasting, pickled or polished
- End:
- bevel end ANSI B16.25
- Production process:
- seamless or welded
- Material:
- Carbon steel stainless steel 304,304l,316,316, 321,347h,310s, s31
Product Description


Porduct Name | ASME B16.9 MSS SP-43 AISI 304/304L/316/316L seamless stainless steel butt weld ss pipe end cap |
Size | 1/2″-24″ seamless,26“-110”welded |
Standard | ANSI B16.9,MSS SP 43, DIN28011, EN10253-4, GOST17379, JIS B2313, MSS SP 75, etc. |
Wall thickness | SCH5S, SCH10S, SCH10, SCH40S,STD, XS, XXS, SCH20,SCH30,SCH40, SCH60, SCH80, SCH160, XXS and etc. |
Type | Ellipsoidal head,pipe end cap,tank head,pressure vessel head,etc. |
End | bevel end/BE/buttweld |
Surface | pickled,sand rolling,brighten,matt polished,mirror polished |
Material | Stainless steel: A403 WP304/304L, A403 WP316/316L, A403 WP321, A403 WP310S, A403 WP347H, A403 WP316Ti, A403 WP317, 904L, 1.4301,1.4307,1.4401,1.4571,1.4541, 254Mo and etc. |
Carbon steel | |
Duplex stainless steel: UNS31803, SAF2205, UNS32205, UNS31500, UNS32750 , UNS32760, 1.4462,1.4410,1.4501 and etc. | |
Nickel alloy: inconel600, inconel625, inconel690, incoloy800, incoloy 825, incoloy 800H, C22, C-276, Monel400, Alloy20 etc. | |
Application | Petrochemical industy;avation and aerospace industry;pharmaceutical industry;gas exhaust;power plant;ship buliding;water treament,etc. |
Advantages | ready stock,faster delivery time;available in all sizes,austomized;high quality |
