304 316 Medical SS Capillary Tube Free Sample
304 316 Medical Stainless Steel Capillary Tube Pipes Piping
SS Capillary Tube Quick Details
- Standard:
- JIS, AiSi, ASTM, GB, DIN, EN
- Type:
- Seamless
- Steel Grade:
- SS 304 316
- Application:
- construction
- Welding Line Type:
- Seamless
- Tolerance:
- ±1%
- Processing Service:
- Bending, Welding, Decoiling, Punching, Cutting, Moulding
- Grade:
- SS 304 316
- Product name:
- 304 316 medical stainless steel capillary tube /pipes/piping
- Material:
- SS 304 316
- Shape:
- Round
- Technique:
- Cold Rolled
- Surface:
- No.1,Polished, Bright,Mirror
- Length:
- Customers’ Request
- Payment terms:
- L/C T/T (30%DEPOSIT)
- Price Term:
- CIF CFR FOB EX-WORK
- Sample:
- Freight Charge Paid
- Certification:
- Sgs
Product Description
| Product Name | stainless steel small diameter tube pipe ss capillary tube |
| Material | stainless steel |
| Out Diameter | 0.3-10mm |
| Thickness | 0.08-1.5mm |
| Standard | DIN GB JIS ASTM EN |
| Grade | 201, 304, 316, 304L, 316L, 321, 310,310S,309,309S,347H, 2205, 2520, 904L |
| Brade | OK Steel |
| Used | machinery, etc. |
| Certification | ISO9001, SGS, BV |
| MOQ | 1 Ton |
| Payment terms | L/C at sight or T/T (30% as deposit) |
| price terms | FOB,CRF,CIF,EXW all acceptable |
| Packing | Export standard package or as customers’ request |
| Delivery time | Usually 7-15 dyas, or upon negotiation |
| Samples | Free samples are provided but the fright is borne by the buyer |
| Grade | C ≤ | Si ≤ | Mn ≤ | P ≤ | S ≤ | Ni ≤ | Cr ≤ |
| 201 | 0.12 | 0.75 | 7.00 | 0.045 | 0.045 | 1.00-1.28 | 13.70-15.70 |
| 202 | 0.15 | 1.00 | 2.25 | 0.045 | 0.045 | 4.07-4.17 | 14.00-16.00 |
| 304 | 0.08 | 0.75 | 2.00 | 0.045 | 0.03 | 8.00-11.00 | 18.00-20.00 |
| 304L | 0.035 | 0.75 | 2.00 | 0.045 | 0.03 | 8.00-13.00 | 18.00-20.00 |
| 309 | 0.15 | 0.75 | 2.00 | 0.045 | 0.03 | 12.00-15.00 | 22.00-24.00 |
| 310S | 0.08 | 1.50 | 2.00 | 0.045 | 0.03 | 19.00-22.00 | 24.00-26.00 |
| 316 | 0.08 | 1.00 | 2.00 | 0.045 | 0.03 | 10.00-14.00 | 16.00-18.00 |
| 316L | 0.035 | 0.75 | 2.00 | 0.045 | 0.03 | 10.00-15.00 | 16.00-18.00 |
| 321 | 0.04-0.10 | 0.75 | 2.00 | 0.045 | 0.03 | 9.00-13.00 | 17.00-20.00 |
| 405 | 0.08 | 0.75 | 1.00 | 0.045 | 0.03 | 0.06 | 11.5-13.5 |
| 409 | 0.089 | 1.00 | 1.00 | 0.045 | 0.05 | 0.06 | 10.50-11.75 |
| 410 | 0.15 | 0.75 | 1.00 | 0.045 | 0.03 | 0.06 | 11.5-13.5 |
| 420 | 0.16-0.25 | 1.00 | 1.00 | 0.040 | 0.03 | 0.06 | 12.00-14.00 |
| 430 | 0.12 | 0.75 | 1.00 | 0.045 | 0.03 | 0.06 | 16.00-18.00 |
| 904L | 0.02 | 1.0 | 2.00 | 0.045 | 0.03 | 23.00-28.00 | 19.00-23.0 |
